TECHNICAL SPECIFICATIONS

 Supply voltage

 6 ... 30 V DC

 Supply current

 output type P

 output type S

 max. 0,6 / 7 mA (OFF / ON state)

 max. 0,6 mA (OFF state)

 Switched current

 output type P

 output type S

 max. 100 mA

 3,3 mA / 40 mA (min. / max.)

 Voltage drop in the closed state

 output type P

 output type S

 1,8 V

 6,0 V

 Output time delay

 0,1 s

 Protection class

 IP68 (0,1 MPa)

 Safety integrity level

 SIL 1

 Cable (for cable outlet performance)

 CLS-23

 CLS-23E

 PVC 2x 0,34 mm2 (3x 0,34 mm2)

 silicone 2x 0,5 mm2

 Weight (with 2 m cable and 30 mm electrode)

 CLS-23 N, E, Xi
 CLS-23 NT, XiT

 aprox. 45 g

 aprox. 190 g

 Output type

 S / PNP

 NAMUR

 N, E, NT,

 Xi, XiT

 Process connection

 M18 x 1,5, M20 x 1,5

 G3/8“, G1/2“, NPT 1/2 – 14
