제품소개
RVM/U-L Series
- 제조사 : meister
- 제조국 : Germany
•스위치/아날로그 선택가능
•0.6 ~ 650 Nl/min
제품사양
| OPERATING DATA | |
Operating pressure, max. | 250 bar (Brass version) 300 bar (Stainless steel version) |
| Pressure drop | 0,02 – 0,4 bar |
| Temperature, max. | 120 °C (optional 160 °C) |
| Measuring accuracy | ±10 % of full scale |
| Operation | Float measuring principle |
Application
| Cooling systems and cooling circuits Mechanical engineering Medical engineering Pharmaceutical industry Chemical industry Research & Development |
MEASURING RANGES | |
Type | Switch range for Air at 1 bar abs. & 20℃ NI/min SCFH SCFM |
RVM/U-L10180 | 60 - 180 125 - 380 |
RVM/U-L10300 | 100 - 300 210 - 640 |
RVM/U-L10650 | 200 - 650 7 - 23 |
| ELECTRICAL DATA | |
Change over (COC) Normally open (NOC) | 250V · 1,5A · 50VA 250V · 3A · 100VA |
Change over M12x1 (-20 °C – 85 °C) Normally open M12x1 (-20 °C – 85 °C) | 250V · 1,5A · 50VA 250V · 3A · 100VA |
| Change over PLC | 250V · 1A · 60VA |
| EX-version in compliance with ATEX directive | |
| ATEX II 2 G Ex mb II T6 & ATEX II 2 D Ex tD A21 IP67 T80 °C ATEX II 2 G Ex mb II T5 & ATEX II 2 D Ex tD A21 IP67 T100 °C | |
| Change over | 250V · 1A · 30VA |
| Normally open | 250V · 2A · 60VA |
| UL Recognized switch contacts | |
| Change over | 240V · 1,5A · 50VA |
| Normally open | 250V · 3A · 100VA |
Electrical connection
| Connector in compliance with EN 175301-803, Form A (DIN 43650, Form A) Connector M12x1 Cable (1 m) |
| EX-version in compliance with ATEX directive | Cable (2 m) |
UL Recognized switch contacts
| Connector in compliance with EN 175301-803, Form A Cable (1 m) |
Ingress Protection
| IP65: Connector in compliance with EN 175301-803, Form A IP67: Cable or connector M12x1 |
Output signal
| The contact opens / changes when the flow decreases below the set point. |
| Power supply | Not required (potential-free reed contacts) |
