제품사양
| OPERATING DATA | |
| Operating pressure, max. | 10 bar |
| Pressure drop | 0,01 – 0,2 bar |
| Temperature, max. | 80 °C |
| Measuring accuracy | ±10 % of full scale |
| Operation | Float measuring principle |
|
Application
|
Mechanical engineering Medical engineering Pharmaceutical industry Chemical industry Research & Development |
| MEASURING RANGES | |
|
Type
|
Switch range for Air Nl/min SCFH SCFM |
| DWG-L1,5 | 3 – 30 6,5 – 63,5 |
| DWG-L3 | 6 – 60 13 – 127 |
| DWG-L8 | 6 – 160 13 – 340 |
| DWG-L12 | 20 – 220 42 – 465 |
| DWG-L18 | 40 – 360 85 – 760 |
| DWG-L35 | 60 – 700 2,1 – 24,7 |
| DWG-L50 | 60 – 825 2 – 29 |
| DWG-L100 | 200 – 1600 7 – 56,5 |
| ELECTRICAL DATA | |
|
Change over (COC) Normally open (NOC) |
250V · 1,5A · 50VA 250V · 3A · 100VA |
| Change over M12x1 (-20 °C – 85 °C) Normally open M12x1 (-20 °C – 85 °C) |
250V · 1,5A · 50VA 250V · 3A · 100VA |
| Change over PLC | 250V · 1A · 60VA |
| EX-version in compliance with ATEX directive | |
| ATEX II 2 G Ex mb II T6 & ATEX II 2 D Ex tD A21 IP67 T80 °C ATEX II 2 G Ex mb II T5 & ATEX II 2 D Ex tD A21 IP67 T100 °C | |
| Change over | 250V · 1A · 30VA |
| Normally open | 250V · 2A · 60VA |
| UL Recognized switch contacts | |
| Change over | 240V · 1,5A · 50VA |
| Normally open | 250V · 3A · 100VA |
|
Electrical connection
|
Connector in compliance with EN 175301-803, Form A (DIN 43650, Form A) |
| EX-version in compliance with ATEX directive | Cable (2 m) |
|
UL Recognized switch contacts
|
Connector in compliance with EN 175301-803, Form A Cable (1 m) |
|
Ingress Protection
|
IP65: Connector in compliance with EN 175301-803, Form A |
|
Output signal
|
The contact opens / changes when the flow decreases below the set point. |
| Power supply | Not required (potential-free reed contacts) |
